LoRaWAN GPS Tracker LA3G

The LA3G LoRaWAN GPS Tracker is a low-power device designed for efficient asset management. It combines GPS positioning with LoRaWAN communication technology, enabling real-time tracking over long distances with minimal power consumption. Compatible with third-party LoRaWAN gateways, the LA3G is quick and easy to set up for various applications.

key features

Real-Time GPS Tracking.
LoRaWAN Bands: EU868, US915.
NFC, BLE (optional) and LoRaWAN remote configuration.
Optional extended GPS antenna via SMA connection

Robust design with IP67 waterproof and dustproof rating
Max.+20 dBm constant RF output & RX sensitivity -148 dBm.
Low power consumption for continuous operation
Operating temperature range of -30°C to 85°C.

what you can do with our Lorawan tracker

Model	KG05 Plug IoT Gateway
Size	30mm30mm55mm(Excluding adapter)
Weight	150g
Material	ABS
Working temperature	-30℃~ + 70℃
Power Supply	100V-240V AC 50/60Hz
Interface	NA
Installation way	AC plug interface
Indicator	RGB LED indicator
Button	1 Config button
LED	Power and network connection status
Firmware Update	OTA

BLE Protocol	BLE4.x, BLE5.0
Bluetooth Frequency	2400MHz ~ 2480 MHz
Wireless Distance	Up to 70 meters of cover radius (open area)
Scanning ability	> 60 packets per second
Concurrent connecting and scanning beacons	Optional
RX sensitivity	-96 dBm @1Mbps,
Transmit power	4 dBm (Max)
Antenna gain	0 dBi

WiFi Protocols	IEEE 802.11b/g/n
WiFi Frequencies	2T2R 2412 MHz ~ 2484 MHz
Data Transfer Speed	IEEE 802.11n: Up to 300 Mbps IEEE 802.11g: Up to 54 Mbps IEEE 802.11b: Up to 11 Mbps
Transmit Power	IEEE 802.11n: 13 ~ 16 dBm IEEE 802.11g: 14 ~ 17 dBm IEEE 802.11b: 16 ~ 20 dBm
Receiving Sensitivity	HT40 MCS7 : -69dBm@10% PER(MCS7) HT20 MCS7 : -71dBm@10% PER(MCS7) 54M: -75dBm@10% PER 11M: -88dBm@ 8% PER
Modulate Mode	DSSS (DBPSK, DQPSK, CCK) OFDM (BPSK, QPSK, 16-QAM, 64-QAM
Network Protocol	HTTP(SSL/TLS) MQTT(SSL/TLS)
Wireless Encryption	WPA-PSK/WPA2-PSK
