IP67 Waterproof Temperature and Humidity Sensor Beacon S5

S5 Bluetooth waterproof Sensor Beacon is a IP67 temperature and humidity waterproof sensor beacon beacon tag with NORDIC ® nRF52 series of extremely-low power ARM ® chipsets.

The S5 waterproof sensor beacon has the shape of a compact case, water resistance design & easy to replace battery, reliable hardware, powerful firmware. It has been designed for cold chain, logistics, vaccine transportation, outdoor Tracking, and service focused on outdoor or indoor.

IP67 Waterproof

Temperature & Humidity Sensor

PHY Coded Long Range

60,000 T&H Logger Records

DESCRIPTION

  • High accurate temperature and humidity sensor beacon
  • IP67 waterproof
  • +8dBm TX power and PHY Coded long range
  • Easy to replace battery
  • Accelerometer sensors optional
  • Compatible with iBeacon, Eddystone (UID, URL, TLM) and KSensor at the same time.
  • All the parameters of this product can be modified via configure APP or Gateway

S5 Waterproof Sensor beacon is compatible with Apple and Android phone, and other BLE4.0/5.0 devices. Moreover, it has also optional accelerometer sensor.  Furthermore, the parameters of the beacon improved with configuring APP.
The transmission range of S5 BLE Beacon is -40 dBm to +8 dBm, the maximum range of S5 waterproof sensor beacon in open space is up to 800 meters.
Some additional features are high/low temperature threshold notification, contactable/non-connectable mode, temperature exceed threshold trigger, motion trigger.
S5 sensor waterproof beacon is available with a custom logo and color. It can also be provided with customizing the configuration.

DOWNLOAD

S5 Waterproof Sensor Beacon
Temperature and Humidity Sensor
IP67 waterproof & Battery replaceable design
Compatible with iBeacon and Eddystone (UID, URL, TLM) and KSensor at the same time.
All the parameters of this product can be modified via configure APP or KGateway.

PRODUCT Application

Specification

Size

Dia. 38mm*12mm

Material

ABS

Color

White (other colors can be customized)

Weight

24g (with battery)

Battery capacity

CR2477 (replaceable)

Battery life

4 years

IP rating

IP67 waterproof

Working temperature

-40℃ ~+70℃

Working humidity

0 ~ 99% RH

Button

1 Button (internal)

LED

1 LED

Sensor

Temperature & Humidity sensor
Acceleration sensor

Config APP

KBeaconPro

Chip

Nordic nRF52 Series

Bluetooth version

BLE 5.0(compatible with BLE 4.x)

TX power

-40dBm ~ +8 dBm

Broadcast Interval

100 ms ~ 40000 ms

Transmit range

• Normal: Maximum 180m(590ft) in open space
• Coded PHY: Maximum 600m(1968ft) in open space

OTA

YES

Temperature measurement

Range: -30℃ ~ 75℃
Measure accuracy:
• 0 ~ 60℃: ±0.4℃
• ≥ -20 and ≤ 0℃: ±0.6℃
• < -20 OR > 60℃: : ±0.8℃

Humidity measurement

Range: 0~100%
Measure accuracy:
• 0 ~ 75℃: ±5%
• ≤0 OR ≥ 75℃: ±5%

Accelerometer

Range: +/-2 g, can be adjustable by firmware
Measure accuracy: +/-32 mg

Type (Slot)

Item

Default settings

Ksensor (on)

Battery level
Temperature
Humidity
Acceleration X/Y/Z

Actual measurements

iBeacon (off)

UUID
Major/Minor
Measured power

Not broadcast by default

Eddystone UID/URL/TLM (off)

Instance ID
Namespace ID
Measured power

Not broadcast by default

System

MAC address
Model ID
Battery percent
Software version

Assigned at factory
59
0 ~ 100
6.x

Password

Password

0000000000000000(default)

Connectable mode

Connectable or not

YES
